Power Supply DC24V (Range: 20.4~26.4V)

---

I/O points 40 points (input 24 points, output 16 points)

---

Output Type Transistor Leak Type (Sink)

---

Memory capacity 20K steps

---

High-speed counter 4-axis × 100kHz (phase difference/unidirectional mode)

---

Pulse output 4-axis × 100kHz (CW/CCW or pulse direction)

---

Built-in analog 4AI 2AO (0~10V/4~20mA, resolution 12,000)

---

Communication Interface 1× USB Programming Port 2× Option Board Slot (Support RS-232C/485, Ethernet, LCD Module)

---

Expansion Capability Up to 7 CP1W expansion units 2 CJ series units, maximum I/O points 320 points

---

Programming Languages Ladder Chart, Structured Text (ST), Function Block (FB)

---

Degree of protection IP20 (in-cabinet installation required)

---

Operating temperature 0~55°C

---

Special Features Interrupt Input ×8, PWM Output, Temperature Compensation, Modbus-RTU Master
