Brief Introduction

REL-MR-24DC/21

Product type: Single relay that is part of a PLC - RPT relay module.Electrical characteristicsInput data: Rated input voltage is 24V DC and input voltage range is 18.5V DC to 33.6V DC at 20°C. At the rated input voltage, the typical input current is 9mA, the typical response time is 5ms, and the typical release time is 8ms. With polarity protection diode and damping diode, the operating voltage is shown as a yellow LED.Output data: 1 changeover contact for contact switching type, single contact type for switching contact, contact material for AgSnO. The maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limited continuous current is 6A, the maximum inrush current is 10A (4s), and the minimum switching current is 10mA (at 12V). The switching capacitances are 2A (at 24V, 13 VDC), 0.2A (110 V, 13 DC), 0.1 A (220 V, 13 DC13), 3A (24 V, AC15), 3A (120 V, AC15), and 3A (230 V, AC15).
