Brief Introduction

REL-MR-24DC/21/MS

Product Type: Single Relay.Electrical characteristicsInput Data: The input voltage is rated at 24V DC and the input voltage range is from 14.4V DC to 66V DC. At the rated input voltage, the typical input current is 7mA, the typical response time is 5ms, the typical release time is 2.5ms, and the coil resistance is 3390Ω±10% at 20°C.Output data: 1 changeover contact for contact switching type, single contact type for switching contact, contact material for AgSnO. The maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limited continuous current is 6A, the maximum inrush current is 10A (4s), and the minimum switching current is 10mA (at 12V). The switching capacitances are 2A (at 24V, 13 VDC), 0.2A (110 V, 13 DC), 0.1 A (220 V, 13 DC13), 3A (24 V, AC15), 3A (120 V, AC15), and 3A (230 V, AC15). The motor load per UL 508 is 1/4HP, 240 - 277V AC (normally open contact), 1/6HP, 240 - 277V AC (normally closed contact).
