Brief Introduction

REL-MR-60DC/21-21AU

Product type: Single relay, miniature power relay with plug-in connection with multi-layer gold-plated contacts.Electrical characteristicsInput data: The input voltage is rated at 60V DC and the input voltage range is 39V DC to 148.8V DC. The drive is monostable and non-polarized, with a typical input current of 8.2mA, a typical response time of 7ms, a typical release time of 3ms, a coil resistance of 7340Ω±15% at 20°C, and a maximum power consumption of 0.49W at rated input voltage.Output data: 2 changeover contacts for contact switching type, single contact type for switching contact, contact material AgNi with hard gold plating. Under normal conditions, the maximum switching voltage is 30V AC, 36V DC, the minimum switching voltage is 100mV (at 10mA), the limiting continuous current and the maximum inrush current are both 50mA, the minimum switching current is 1mA (at 24V), and the maximum power rating (resistive load) is 1.2W (24V DC). When the gold plating layer is destroyed, the maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limiting continuous current is 8A, the maximum impulse current is 15A (300ms), the minimum switching current is 10mA (at 5V), and the maximum rated power value (resistive load) will change accordingly, such as 190W (24V DC), 85W (48V DC), 60W (60V DC), etc. The switching capacitance is 2A (at 24V, DC13), 0.2A (at 110V, DC13), 0.2A (at 250V, DC13), etc.
