12.1" high-definition display with 16 million true colors;
Dual Ethernet ports and dual serial ports design, worry-free communication;
Quad-core CPU with 1GB memory and 8GB flash memory, ultimate performance;
Metal shell and triple protection coating and power isolation, safe and reliable;
">| Performance Specification | Electrical Specification | Structure specification | ||
| Display size | Input range | PCB | ||
| 12.1″TFT | DC18V～DC28V,built-in isolated power supply | Built-in | ||
| Display area | Power | Shell material | ||
| 261.12mm(H) x 163.20mm(V) | 15W@DC24V | Metal | ||
| Resolution | Allowable loss of power | Shape size | ||
| 1280*800 px | <3ms | 313*235*48.5mm | ||
| Display color | Insulation resistance | Cutout size | ||
| 16.77M | Over 50MΩ@500V DC | 295*217mm | ||
| Visual angle | Hi-pot test | Installation mode | ||
| 85/85/85/85(L/R/U/D) | 500V AC 1 minute | Installation of Fasteners and VESA Mounting(VESA100*100mm) | ||
| Contrast | Weight | |||
| 1200:01:00 | Environmental Specification | 5KG | ||
| Backlight | Working temperature | |||
| LED | 0~50℃ | Product Certification | ||
| Luminance | Working humidity | Panel protection grade | ||
| 500cd/m² | 10~90%RH (non-condensing) | Conforming to IP65 certification (4208-93) | ||
| LCD life | Storage temperature | CE certification | ||
| ＞50000 hours | -20~60℃ | EN IEC61000-6-4:2019，EN IEC61000-6-2:2019 | ||
| Touch panel | Storage humidity | |||
| 4 line precision resistance network | 10~90%RH (non-condensing) | |||
| CPU | Sine vibration test | |||
| Quad-core 1.8GHz | 10~500Hz, 30m/s², X,Y,Z direction/hour | |||
| Memory | Cooling mode | |||
| 8GB Flash Memory+1GB Memory | Natural air cooling | |||
| RTC | ||||
| Built-in(512KB) | Software | |||
| External storage | Configuration software | |||
| 1 USB Host | Kinco DToolsPro | |||
| Printer port | ||||
| USB Host/Serial port | ||||
| Ethernet | ||||
| LAN0:10/100/1000 Mbps;LAN1:10/100 Mbps | ||||
| Program download | ||||
| Ethernet port/USB Slave/U disk | ||||
| Communication | ||||
| COM0:RS232/RS485/RS422;COM2:RS232; |
