Features

• Available in 10-point, 16-point or 32-point digital I/O versions
• Analog versions available with 20 digital I/O points, 4 analog inputs (two voltage and two current) and 1 analog output (configurable for either voltage or current)
• Provides a compact form factor, with footprints as small as 120 mm x 80 mm x 40 mm (4.72 in. x 3.15 in. x 1.57 in.)
• Offers fast processing with typical throughput time of 1.5 ms for a 500-instruction program
• Preconfigured 1 KB program and data memory to ease configuration
• Includes built-in EEPROM memory; no need for battery back-up or separate memory module
• Provides peer-to-peer messaging (up to 32 controllers on a DH-485 network) through a 1761-NET-AIC communication interface
• Communicates via DeviceNet™ and EtherNet/IP™ through 1761-NET-DNI and 1761-NET-ENI communication interfaces
• Includes a built-in high-speed counter (only on controllers with 24V DC inputs)
• Lets you customize input response time and noise rejection using adjustable DC input filters
• Supports simple connectivity through RS-232 communication channel to a PC for program upload, download and monitoring

Products

• 1766-L32BWAA 32 PT ML1400DC IN/RELAY OUT W ANALOG IO

Description:

The 1766-L32BWAA is a MicroLogix 1400 Controller under the Bulletin 1766 product family. This compact controller features integrated Three (3) communication ports such as a combo RS232 / RS485 port, isolated RS232 port and an Ethernet communication port. It has embedded Input and Output channels which consists of Twenty (20) digital 120V AC inputs, Four (4) 0-10VDC analog inputs, Twelve (12) Relay outputs and Two (2) 0-10VDC analog outputs.

Applications

Typical applications for the MicroLogix™ programmable controllers include:

• Material Handling
• Packaging Applications
• General Industrial Machinery
• Printing
• Food and Beverage
• Pharmaceutical
• Water Wastewater / SCADA
• Clutch/Brake control
• Position Control - Pick-and-place / Conveyor
