Industrial serial port server series products, mainly realize the data transmission between Ethernet and serial port (RS-232/RS-485/RS-422), it integrates the TCP/IP protocol stack, RS-232/RS-485/RS-422 devices that are not connected to the Internet can also be easily, flexibly and quickly connected to Ethernet. The series of products use high-performance ARM chip to ensure stable data transmission; Support a variety of working modes to meet different application requirements; Excellent anti-interference performance, suitable for harsh industrial environments.
Benefits:
- Support 2-channel RS232/485 to Ethernet
- Support Modbus RTU/ASCII to Modbus TCP
- SupportTCP Server/TCP Client/UDP/UDP multicast/RealCom/Pari Connection/HTTPD and other working modes
- Support custom subcontracting length and interval, etc
- Working temperature:-40°C~85°C, DC9~36V wide voltage, guide rail installation
| Product model | NS302R |
| CPU platform | 32-bit Arm Cortex-M7 core, up to 400MHz clock |
| Serial - Number of ports | 2 x RS-232/RS-485 |
| Serial-interface form | 14-position 3.5mm pitch terminal block |
| Serial port - communication rate | 600~460800bps |
| Serial port - data format | Support data bits: 8 bits, stop bits: 1~2 bits, check bits: no check/ODD odd check/EVEN even check |
| Number of RJ45 network ports | 1 x 10Base-T/100Base-TX, support automatic flow rate control, full-duplex/half-duplex communication mode and MDI/MDI-X automatic identification |
| RJ45 network port - isolation protection | 6KV lightning protection, 1.5KV isolation protection |
Electricity | External DC: DC9~36VDC, the power interface supports two access modes: BNC connector (φ2.5mm) and 2-digit 5.08mm pitch industrial-grade terminal block, and supports anti-reverse polarity protection function |
| Consumption | 43mA（@12VDC） |
| ESD indicators | ± 6kV contact discharge, ± 15kV air discharge |
Ingress protection | Surge Protection: Power : ±2kV/common mode, ±2kV/differential RS485/422: ±2kV/common mode, ±2kV/differential Ethernet port: ±6kV/common mode, ±2kV/differential mode EFT Test: Power supply: ±2kV, communication port: ±2kV |
| Product Certification | CE、FCC、RoHS |
| Exterior dimensions | 112mmX73mmX34mm |
| Operating temperature | -40℃～+85℃ |
| Storage temperature | -40°C~+85°C 5%~95% RH (no condensation). |
| Software parameters | |
| Network protocols | IPv4、TCP、UDP、Modbus |
| Configuration | WEB CONFIGURATION |
| Simple transparent transmission method | TCP Server/TCP Client/UDP/Modbus RTU |
| Serial port data packaging mechanism | The interval and length can be set, the default value varies according to the bit rate, and the maximum package length is 1460 bytes |
| The number of client connections | A maximum of eight TCP client connections can be connected in TCP Server mode |
| Network caching | Send: 16Kbyte Receive: 16Kbyte |
| Serial port cache | Send: 1.5Kbyte Receive: 1.5Kbyte |
| Heartbeat pack | TCP keepalives are supported |
| Average transmission delay | <10ms |
