Model | EM223 16 inputs/16 outputs Relay |
Product Description | 16DI,24VDC/16DO, 24 VDC/250VAC, Relay isolation with high immunity. |
From bus current consumption | 140mA |
Power loss | 5.2W |
Digital Input Specification |
|
Number of digital inputs | 16 |
Input voltage | 24 VDC,4mA |
Logic 0 signal | 0~5 VDC |
Logic 1 signal | 15~30 VDC |
Maximum Input Delay Time | 4.5ms |
Signal input type· | PNP/NPN |
Optical isolation(Galvanic) | 500 V AC for 1 minute |
Cable Length (Shielded) | 500m |
Cable Length (unshielded) | 300m |
Digital Output Specification |
|
Number of digital outputs | 16 |
Output type | Relay |
Isolation | Relay |
Output voltage | 24 VDC |
Output voltage range | 5~30 VDC/20~250V AC |
Output Current | 2.0A |
Lamp load | 30W DC/200W AC |
Lifetime contact mechanical | 10,000,000 |
Lifetime contact mechanical (rated load voltage) | 100,000 |
Cable Length (Shielded) | 500m |
Cable Length (unshielded) | 150m |
Dimensions(W x H x D)(mm) | 137.5×80×62 |
Order Number | 223-1PL22-0XA0 |
