1 Port RS232/485 Serial to 100M Ethernet Server

★★★★★4.92911 Reviews

Wholesale Price

Model: NS301R

Order No: NS301R

SKU: 10000144124401

Category: Serial server

Brand: MoweStar

Size: 87.50mm, 36.50mm, 58.60mm,0.00cm

Weight: 0.80kg

Product Selection Engineer: Huankanheng

Leading

Customer Service Guarantee

100% secure payment

Quality Guarantee

No Reason Returns

You May Also Like

Selling List

Description Reviews

1 Port RS232/485 Serial to 100M Ethernet Server

● RS-232/RS-485 serial interface up to 2kV surge protection

● Up to 6kV lightning protection on Ethernet interface

● Support Modbus RTU/ASCII to Modbus TCP conversion

● Support VirtualCOM software management

● Din Rail installation

1 Port RS232/485 Serial to 100M Ethernet Server

SPECIFICATION
Product model		NS301R
functional description		Industrial grade rail type single serial server
Hardware parameters
functional description		32 bit Arm architecture M7 kernel, up to 400 MHZ frequency
Serial port - Number of ports		Serial port - Number of ports
Serial port - Indicates an interface		The RS - 232 / RS - 485 interface: 5-bit 5.08mm pitch industrial grade terminal
Serial port - Communication rate		600~460800bps
Serial port - Data format		Support data bits: 7, 8 bits, stop bits: 1, 2, check digit: no check/ODD ODD/EVEN parity
RJ45 Network ports - Number of ports		One 10BASE-T / 100BASE-TX supports automatic flow rate control, full-duplex/half-duplex communication mode, and MDI/MDI-X automatic identification
RJ45 Network port - Isolation protection		6KV lightning protection, 1.5kV isolation protection
The power supply		External DC supply :DC5~36VDC
Power consumption		43mA（@12VDC）
The isolation voltage		-
ESD indicators		±6kV contact discharge ±8kV air discharge
Protection grade	power supply	±2kV/common mode ±2kV/differential mode
	RS485/422	±2kV/common mode ±2kV/differential mode
	network port EFT	±6kV/common mode ±2kV/differential mode
	test	Power supply: ±2kV, communication port: ±2kV
Installation method		rail type
Exterior size		87.5X36.5X58.6(mm)
Operating temperature		-40℃〜+85℃
storage temperature		-40℃～+85℃ 5%～95% RH (non-condensing)
Software parameters
Network protocol		IPv4、IP、TCP/UDP、ARP、ICMP、DHCP、DNS、HTTP、RFC2217
Configuration method		WEB page configuration
Simple transparent transmission		TCPServer/TCPClient/UDPClient/UDPMulticast/RealCOM/PairConnection
Modbus		Modbus RTU/ASCII to Modbus TCP
Serial port data packaging mechanism		The interval time and length can be set; the default value varies according to the bit rate; the maximum packet length is 1460bytes
TCPServer support Number of Client connections		Support 8-way TCPClient connection
web cache		Send: 16Kbyte Receive: 16Kbyte
Serial port cache		send: 1.5Kbyte receive: 1.5Kbyte
heartbeat pack		Support TCP Keepalive mechanism, customize heartbeat packet content
average transmission delay		<10ms
Certification		CCC , CE , FCC , RoSH
packing list		Serial server1 12V power adapter1 1M test network cable1 1.5M female to female serial cable1
