Industrial serial port server series products, mainly realize the data transmission between Ethernet and serial port (RS-232/RS-485/RS-422), it integrates the TCP/IP protocol stack, RS-232/RS-485/RS-422 devices that are not connected to the Internet can also be easily, flexibly and quickly connected to Ethernet. The series of products use high-performance ARM chip to ensure stable data transmission; Support a variety of working modes to meet different application requirements; Excellent anti-interference performance, suitable for harsh industrial environments.
● RS-485/RS-422 serial interface up to 4kV surge protection
● Up to 6kV lightning protection on Ethernet interface
● Support Modbus RTU/ASCII to Modbus TCP conversion
● Support VirtualCOM software management
● Support opto-isolation
Power supply | |
Working Voltage | 9~36V |
Working current | 78mA@12V |
Network port | |
Network port type | 10 / 100Mbps, RJ45 interface; adaptive MDI / MDIX cross-connect and auto-flip |
Isolation protection | 1.5KV isolation protection |
Serial port | |
Number of serial ports | 2* RS485/RS422 working mode, choose one of two |
Baud rate | 600~460800 (bps) |
Data bit | 7, 8 |
Stop bit | 1, 2 |
Validation modes | none, odd parity, even parity |
Connector | DB9 for RS232, ternimal blocks for RS485/422 |
Isolate power supply | 3kV |
Reliability | |
ESD | ±8kV(contact); ±15kV(air) |
Surge | Power supply: ±4kV / common mode, ±4kV/ differential mode |
RS485/ 422: ±4kV / common mode, ±4kV/ differential mode | |
Network port: ±6kV/ common mode, ±4kV/ differential mode | |
EFT | Power supply: ±4kV Communication port: ±2kV |
Mechanical structure | |
Size | 162mm*29mm* 95mm (length* height*width) |
Working environment | |
Operating temperature | -40°C~85°C |
Storage temperature | -40°C~85°C |
Relative humidity | 5%~95% (no condensation) |
Software parameters | |
Network Protocols | ICMP, IPv4, IP, ARP, TCP, UDP, DHCP, DNS, HTTP, RFC2217 |
IP acquisition method | Static IP/DHCP |
DNS | Support |
User configuration | Web configuration |
Simple transparent transmission | TCP_Server/TCP_Client/UDP_Client/UDP_Multicast/RealCOM/Pair_Connection |
Modbus | Support Modbus RTU / ASCII to Modbus TCP (Master and Slave Mode) Support Modbus Over TCP Modbus TCP to Modbus RTU |
Serial port packaging mechanism | Time and length can be set; The default value varies according to the bit rate; The maximum packing length is 1460 bytes. |
TCP Server connection | Support up to 8 TCP connections |
Network cache | Send: 16Kbyte; Receive: 16Kbyte |
Serial port cache | Send: 1.5Kbyte; Receive: 1.5Kbyte; |
Flow Control | Auto Flow Control |
Heartbeat bag | Support network port custom heartbeat package |
Average transmission delay | <10ms |
Supporting software | Network Configuration Tool, VirtualCOM, MWView, MaxView |
