UT-6804 serial device server provides serial port to network function, which can convert RS-232/485/422 serial port to TCP/IP network interface and realize bidirectional transparent transmission of data between RS-232/485/422 serial port and TCP/IP network interface. Enables serial devices to have TCP/IP network interface function immediately.
- With metal housing and multiple mounting design, suitable for industrial applications
- Wide power input (12~48VDC), suitable for different power supply methods
- Up to 4 RS232/RS485/RS422 ports for multi-serial applications
- Wide baud rate range of 300-921600bps, suitable for inter-device applications
- Support multiple operation modes: VCOM, MCP, TCP SERVER, TCP CLIENT, UDP, Remote Pair mode, Modbus TCP SERVER, Modbus TCP CLIENT, MQTT.
- Support secondary development of software, to meet the special applications of different scenarios.
- Support for Web firmware upgrades for special applications in different scenarios
Technologu parameters
| UT-6804 | UT-6804MT |
Processor | 32bit 400MHZ | 32bit 400MHZ |
Storage | 128M | 128M |
Ethernet interface | 10/100M(Built-in 1.5KV electromagnetic isolation) auto MDI/MDI-X Ethernet interface, interface RJ45 | 10/100M（Built-in 1.5KV electromagnetic isolation）auto MDI/MDI-X Ethernet interface, interface RJ45 |
Serial Standard | RS-232, RS-485, RS-422 | RS-485, RS-422 |
Serial Connector | 4×RJ45 | 4×4Pin 3.81mm terminals |
Indicator light | Power indicator light PWR, Running indicator light RUN | Power indicator light PWR, Running indicator light RUN |
Power connector | DC-005 DC socket or 3Pin 5.08 terminal for power supply, with built-in protection against reverse connection, to avoid damage to the equipment by wrong positive and negative connection | DC-005 DC socket or 3Pin 5.08 terminal for power supply, with built-in protection against reverse connection, to avoid damage to the equipment by wrong positive and negative connection |
Power range | DC12~48V | DC12~48V |
Function buttons | 1 factory reset button RESET | 1 factory reset button RESET |
Max. power consumption | 2W | 2W |
Housing | Metal housing, protection level IP30 | Metal housing, protection level IP30 |
Operating environment | Storage temperature: -40~85°C Operating temperature: -40~85°C Relative humidity: 5 ~95% (Non-condensation) | Storage temperature: -40~85°C Operating temperature: -40~85°C Relative humidity: % ~95% (Non-condensation) |
Dimensions L×W×H | 161mm×91mm×37mm（Without mounting parts） | 161mm×91mm×37mm（Without mounting parts） |
Net. Weight | 350g | 350g |
Software parameters
Operating System | Based on Linux |
Protocol support | ARP,IP,ICMP,UDP,TCP,HTTP,DHCP,SNMP,MQTT,MODBUS |
Configuration method | Web browser, VCOM Utility(Virtual COM Only Windows) |
Operating Mode | VCOM,MCP,TCP SERVER,TCP CLIENT,UDP,Remote Pair mode,Modbus TCP SERVER,Modbus TCP CLIENT, MQTT |
Baud rate | 300-921600bps |
Data Bits | 5,6,7,8 |
Stop Bits | 1,2 |
Check Bits | None,Odd,Even |
Flow Control | RTS/CTS,DTR/DSR,XON/XOFF（Only RS-232） |
Module | Supply Voltage | Connection | Communication Mode |
UT-6804 | 12-48V | RJ45 | RS-232/RS-485/RS-422 |
