1. Infrared remote control + magnetic rod operation, simple and convenient.
2. Support independent networking and wireless transmission.
3. Abundant output interfaces.
4. Support two-wire communication.
5. Protection grade IP66, splash-proof.
6. Integrated functional module design.
| Product parameters | ||
| Detection Gas: | Transmission mode: | |
| Flammable + toxic gases | (1) 4-20mA transmission: RVVP 1.0² three-core, four-core, cable, transmission distance 1km | |
| Measuring range: | (2) RS485 transmission: RVSP 1.0² two-core, four-core shielded wire, transmission distance 3km | |
| 0-100μmol/mol | (3) Cloud server: 4G transmission data of the data acquisition instrument is connected to the Wosette cloud server, and the data can be viewed through the user's computer and mobile phone WeChat (optional) | |
| Resolution: | (4) LoRa transmission: with routing mode, it can realize any networking of large quantities of instruments, and the transmission distance can reach 3km (optional) | |
| 1μmol/mol | Receiving Equipment: | |
| Detection method: | User computer, control alarm, PLC, DCS, mobile phone, tablet computer, etc. are optional | |
| Diffusion | Alarm mode: | |
| Response time: | On-site sound and light alarm, external alarm, remote controller alarm, computer data acquisition software alarm, mobile APP notification, SMS alarm optional (optional) | |
| ≤30S | Alarm settings: | |
| Alarm mode: | (1) Standard configuration of two-level alarm | |
| Alarm light + sound | (2) The gas sensor can set two alarm modes: conventional high and low alarm and interval control, and can control the concentration range of gas | |
| Product variant: | Housing Material: | |
| LCD display + alarm light; LCD model | Die-casting aluminum + sandblasting oxidation/fluorocarbon paint, explosion-proof and anti-corrosion | |
| Gas Type: | Working Environment: | |
| Single gas | (1) Operating temperature: -30 ~ 60°C | |
| Ingress Protection: | (2) Working humidity≤95%RH, no condensation | |
| IP66 | (3) Working pressure: -30Kpa ~ 100Kpa | |
| Explosion-proof marking: | Product Size: | |
| Exd II CT6 Gb | LCD 249*172*91mm; LCD+sound-light model 262*202*91mm | |
| Installation: | Standard Accessories: | |
| Wall-mounted, bracket-mounted, tube-hugging type | Manual, certificate, factory test report, mounting bracket, remote control | |
| Signal Output: | Executive Standards: | |
| (1) 4-20mA signal: the standard analog current signal transmission distance is 1km | GB3836.1-2010 "Explosive atmospheres – Part 1: General requirements for equipment" | |
| (2) RS485 signal: using standard MODBUS RTU protocol, transmission distance 1km | GB3836.2-2010 Explosive atmospheres – Part 2: Equipment protected by flameproof enclosure "d" | |
| (3) Switching signal: 1 set of relays and passive contacts as standard | ||
| (4) 1 Powerbus interface | ||
